ZERAMEX® XT | Full ceramic posterior bridge
21
Jan
Jan
About the Doctor
Dr. Michael Leistner
Website
Curriculum vitae:
- Born in 1957
- 1978 high school diploma
- 1978 – 1981 Training in dental technology
- 1989 exam, license and doctorate at the Albert-Ludwigs-University Freiburg
- 1989 Scientific work for Krupp Medical Technology with a focus on titanium welding
- 1990 – 1991 Assistant professor
- 1991 established in his own practice
- 1994 Speaker on all-ceramics
- 2001 Winner of the open Russian championships in stomatology
- 2002 lecturer on implantology
- 2003 International lecturer
- 2005 Speaker on the subject of metal-free pens
- 2007 Foundation of a national practice group
- 2009 Dental license in Porto (Portugal)
- 2012 Speaker on all-ceramic implants
ZERAMEX® XT | Full ceramic posterior bridge
The 72-year-old patient has been treated with seven titanium Straumann implants and a double-sided sinus lift in the upper jaw over 20 years ago. The two implants on 24 and 25 had to be removed due to severe peri-implantitis and bone resorption. The patient wanted to know, whether a further implant soluton is possible. After evaluation of the X-ray images, a new restoration on the basis of three implants in the second quadrant was proposed, in the distal area bone augmentation via an internal sinus lift. The patient asked if a metal-free restoration is possible. The implants used were the new Zeramex XT implants with screw-retained abutments (Dentalpoint). The bone replacement material used was maxresorb inject (botiss).
1- OPG two years before re-implantation.
2- OPG three months after removing the old implants.
3-OPG after placement of the 3 XT ceramic implants.
4- OPG after prosthetic restoration.
5-View of the operating area, existing bridge unit 23 will be removed.
6- Access to the bone through tissue punching. Pontic 23 has been removed.
7-Removal of the punched gingiva.
8-After marking and pilot drilling, shaping the implant socket with ZERADRILL.
9-After tapping, inserting the first implant.
10- Insertion of the bone substitute material for the internal sinus lift for the 2nd implant.
11-Carefully screw in the 2nd implant with the hand ratchet.
12-Site after 3 months.
13-Exposing the healing caps.
14-The exposed implants
15- Transfer sleeve for closed impression in place.
16-Another view of the transfer sleeve.
17-Gingivaformers and a healing cap after the impression.
18- Occlusal view of the CAD framework.
19-Buccal view of the CAD framework.
20- Palatal view of the CAD framework.
21-Screw-on abutments on the model.
22- Insertion key from Palavit G (Kulzer).
23-Finished bridge on the model.
24-Healed gingiva after three weeks.
25-View of the new implant connection geometry.
26-Cleaning the inside with Curaprox rotary brush.
27-Cleaning the interior with a hydrogen peroxide solution.
28-Screwing in the abutments with the insertion key.
29-Abutments in place prior to final torquing to recommended value.
30-Insertion key removed and Viacrbo screws torqued to 25 Ncm.
31-Closing the screw access opening with Teflon tape.
32- Applying bonding agent on zirconia abutments
33- Applying adhesive to bridge prior to cementation.
34- Palatal view of bridge.
35- Occlusal view of bridge.
36- Buccal view of bridge.
