ZERAMEX® XT Implant dia. 5.5 x 12mm WB (incl. Healing Cap)
The ZERAMEX® XT dental implant is the newest member of the family of two-piece, reversible-thread ZERAMEX® ceramic implants.The ZERAMEX® XT ceramic implant is placed 1.6 mm supracrestally (optionally up to 0.6 mm) and offers great prosthetic flexibility. The implant thread was developed to achieve high primary stability. The reservoir for bone chips at the implant tip simplifies the placement of the implant.The ZERAMEX® XT ceramic implant is manufactured from hard zirconium dioxide ATZ blanks manufactured by hot isostatic pressing. No thermal process (sintering) or post-processing takes place after the final shaping of the outer and inner geometry of the implant. This ensures that a high degree of precision is achieved and no further changes can occur in the material structure. This manufacturing process is very complex and requires a great deal of experience and know-how.
ZERAMEX® XT Connection
BOLT-IN-TUBE » INTERNAL CONNECTION
The four cross-shaped retentive elements provide an ideal transmission of torque when inserting the implant, allowing the dental implant to be screwed into the bone without stress peaks.
FOUR TIPS FOR MORE PRECISION
The special geometry with the four tips enables high precision and fast and easy insertion and alignment of the abutment.
The heart of the connection is the VICARBO® screw.
It works like a bolt, which anchors the abutment in the implant. The extremely hard ceramic is combined with a very stiff, carbon fibre-reinforced high-performance peek. In a way similar to reinforced concrete, the ceramic absorbs the compressive forces, while the VICARBO® screw counteracts tensile forces.
|dia. 4.2mm||Art no.||name||dimension||Link|
ZERAMEX® XT Implant dia. 4.2 x 8mm RB (incl. Healing Cap)
ZERAMEX® XT Implant dia. 4.2 x 10mm RB (incl. Healing Cap)
ZERAMEX® XT Implant dia. 4.2 x 12mm RB (incl. Healing Cap)
ZERAMEX® XT Implant dia. 4.2 x 14mm RB (incl. Healing Cap)
